Wavelength	Product model	Die size	Output power
810nm / 850nm	D-V0810M-1000-0029 D-V0850M-1000-0029	29Mil (725μm x 725μm)	1W
810nm / 850nm	D-V0810M-2000-0042 D-V0850M-2000-0042	42Mil (1080μm x 1050μm）	2W
810nm / 850nm	D-V0810M-3000-0043 D-V0850M-3000-0043	43Mil （1075μm x 1120μm）	3W

 * We offer customization services for the above and other products, please contact our sales center for details.

Features

• VCSEL

• High efficiency and reliability

• Stable central wavelength, narrow line width

• Doughnut shaped, symmetrical far field

• Surface mountable

Applications

• Sensor light source

• Consumer electronic products

• Machine vision

• Infrared lighting

• Industrial applications
